China Guangzhou Silicone Vacuum Compression Molding Machine For Making Baby Nipple

Name: China Guangzhou Silicone Vacuum Compression Molding Machine For Making Baby Nipple
Brand: JUCHUAN
Price: 28 USD

Wholesale China Guangzhou Silicone Vacuum Compression Molding Machine For Making Baby Nipple from china suppliers

Place of Origin : Guangdong, China

Model Number : JC-VF

Brand Name : JUCHUAN

Certification : ISO9001:2015

Packaging Details : shring film packing

Supply Ability : 1000 Set/Sets per Month injection machine

Price : $28,000.00 - $48,000.00/sets

MOQ : 1set

Payment Terms : L/C, T/T, Western Union

Delivery Time : 45 days

Condition : New

Style : VERTICAL

Ejector Stroke(mm) : 250 mm

Ejector Force(kN) : 2000 kN

Theoretical Shot Volume(cm³) : 1000 cm³

Injection Rate (g/s) : 100 g/s

Machine Type : Hydraulic

Injection Weight (g) : 100 g

Screw diameter (mm) : 35 mm

Weight (KG) : 8000

Type : Plate Vulcanizing Machine

Open Stroke(mm) : 250 mm

Power (kW) : 24 kW

Warranty : 1 Year

Key Selling Points : Competitive Price

Applicable Industries : Manufacturing Plant

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Motor, Pump, PLC

After-sales Service Provided : Engineers available to service machinery overseas, Video technical support, Online support

Automatic : yes

Distance of Tie bar(mm) : 785*380

Plunger Stroke(mm) : 300

Upper Platen Size (mm) : 680*680

Lower Platen Size(mm) : 700*800

Plastic Type : Other

Clamping Force (kN) : 2000

After Warranty Service : Video technical support, Online support

Port : Guangzhou

Contact Now

China Guangzhou Silicone Vacuum Compression Molding Machine For Making Baby Nipple

Product Description

Specific Characteristic:

Twin work position design, are required with independent oil circuit, dual oil pump, double motor.
Vacuum pumping device draws out air in die cavity to avoid trapped gas, short injection, shorten forming period and improve product quality.
Suitable for rubber parts with complicated structure and difficult exhaust.
Open the mold design: a new type of patent guide rail. Special design can be 90 degrees open angle, easy to operate.
Mold handling design: in the mold handling agencies to join a special design. It is durable and quiet. Fast and outdated.
Hydraulic System Design: The system uses high-pressure pump and low-pressure pump, which can shut down two presses at the same time. The system is less noise, stable performance, and long service life.
Alignment: provide two different mold calibration speeds: fast and slow, the user can choose to use according to the actual situation. It makes calibration more secure and accurate.

2RT Machine motion flow:

1. Setup the mold (initial status)

2. Supply the material and start the process(close the mold)

3. Load the mold

4. The main ram goes up to the predetermined position ready for entering a state of vacuum

5. Lower the vacuum mask. At the same time, suck out the air until a state of vacuum is reached.

6. The main ram goes up. Increase the pressure to expel bubbles out.

7. After the state of vacuum exist mo more, lift the vacuum hood and curing.

8. After curing, lower the main ram.

9. Unload the mold, open the mold.

10. Take out the final product and put new material in.

Technical parameter

Technical parameter:

Model	Unit	100VF	200VF	250VF	300VF
Clamping Force	Ton	100	200	250	300
Upper Platen Size	mm	380*400	510*510	600*600	680*680
Lower Platen Size	mm	400*460	550*560	650*600	700*800
Plunger stroke	mm	200	250	250	300
Distance of Thermo-plate	mm	200	250	250	300
Distance of Tie bar	mm	490*230	640*310	745*310	785*380
Die sinking type	2RT-3RT-4RT-Track
Max Operating Pressure	Mpa	20	20	20	20
Motor Power	hp	7.5*2	10*2	10*2	10*2
Electric Heating Power	Kw	7.2*2	13.5*2	15.3*2	24*2
Vacuum Pump Power	Kw	3	3	3*2	3*2
Total Power	Kw	28.4	45	51.6	69
Gross weight	Ton	5	7.8	11	15.45
Dimension	mm	L2500W2150H2080	L2930W2500H2350	L3190W2930H2495	L3360W2970H2850

China Guangzhou Silicone Vacuum Compression Molding Machine For Making Baby Nipple

Our Services

Our service:

1. Free technology training: you can come for inspection and training for free.

2. Free Installation and debugging: Our engineers will teach you about the installation and debugging for free.

3. After-sales service: We will supply the free repairmen on this machine for one year, but will supply the maintenance lifetime. (The service is only for natural damage)

4. Online remote control for software problems, whatspp or wechat for video checking.
